उत्पाद विवरण:
|
|
उत्पत्ति के प्लेस: | चीन |
---|---|
ब्रांड नाम: | Glawall |
प्रमाणन: | SGS, ISO 9001,UL, CE |
मॉडल संख्या: | पूरी तरह से मॉड्यूलर डबल ग्लास दीवार |
दस्तावेज: | 25mm.pdf |
भुगतान & नौवहन नियमों:
|
|
न्यूनतम आदेश मात्रा: | 10 स्क्वायर मैटर्स |
मूल्य: | US$80.00 10 - 99 square meters |
पैकेजिंग विवरण: | प्लाईवुड |
प्रसव के समय: | 20-25 दिन |
भुगतान शर्तें: | एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन |
आपूर्ति की क्षमता: | प्रति माह 3000 वर्ग मीटर |
विस्तार जानकारी |
|||
फ़ायदा: | प्रतिस्पर्धी मूल्य, अच्छी सेवा, उच्च पेशेवर, गुणवत्ता की गारंटी | मूल स्थान: | ग्वांगडोंग, चीन |
---|---|---|---|
फैक्टरी प्रमाणन: | हाँ | कारखाना क्षेत्र: | 20000 वर्ग मीटर |
सामग्री: | एल्यूमिनियम फ़्रेम, ध्वनिक पैनल | ध्वनिरोधन: | 38-45DB |
पैनल मोटाई: | 60, 90.108 मिमी | ग्लास प्रकार: | मजबूत टेम्पर्ड ग्लास |
वेंटिलेशन: | वायुप्रवाह प्रणाली | गारंटी: | 2 साल |
प्रमुखता देना: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
उत्पाद विवरण
Advantage | Competitive price, good service, high professional, quality guarantee |
Place of Origin | Guangdong, China |
Factory Certification | Yes |
Factory Area | 20000 square meter |
Material | Aluminum Frame, Acoustic Panels |
Soundproofing | 38-45dB |
Panel Thickness | 60, 90, 108mm |
Glass Type | Strong tempered glass |
Ventilation | Airflow System |
Warranty | 2 Years |
Feature | Benefit |
---|---|
Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
Tool-Free Connection | Patented click-lock system secures panels without tools |
Fast Installation | 2-person team can install 20m² in under 3 hours |
42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
Step | Action |
---|---|
Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
Step 3 | Snap decorative covers over joints for perfect alignment |
Feature | Specification |
---|---|
Frame | 90mm powder-coated aluminum (20+ RAL colors) |
Glass | 5+5mm tempered (clear/frosted/tinted options) |
Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
Fire Rating | EI30-EI60 available |
Max Height | 4m without additional support |
For Contractors | For Clients |
---|---|
70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
